Standard Test Gauge, 0.6 % accuracy, model G11

  • Size: 100 mm
  • Accuracy : 0.6 % FS as per EN 837-1
  • Range from 0 to 600 mbar up to 1600 bar
  • Mounting: Direct Surface mounting, G12
  • Case & Ring: Stainless Steel
  • Socket: AISI 316 stainless Steel
  • Movement : Stainless Steel
  • Safety: S1 as per EN 837-2.
  • Dual Scale Bar/PSI
  • Pointer : adjustable, aluminum, black.
  • Dial: aluminum, white with black markings
  • Bourdon tube, seamless tube: AISI 316L st.st

Description

The G11 mechanical test gauge has been specifically designed for the measurement of pressures with high accuracy. With its accuracy class of 0.6, the Bourdon tube pressure gauge is suitable for testing industrial type pressure gauges or for precision measurement in laboratories.

The G11 fit perfectly as reference test gauge in conjunction with our range of  Calibration Hand Pumps
